Contour based netlist extraction is fast and accurate - providing Bare Board Test information including accessibility.
The powerful editing tools allow yield enhancement to be performed quickly and effectively. Pad Shaving, Soldermask Adjustments and Silkscreen Clipping are just some of the advanced editing tools included as standard.
Netlist comparison can also occur between two Gerber netlists allowing a sanity check of data before and after editing. A common user interface is used to display DFM errors and Netlist Comparison errors to aid usability. Differences are categorized by Open, Short, Missing or Extra and graphically highlighted on screen. Multiple DFM Analysis results can be stored and analysis can be performed on partial areas of the board as required.Ĭomparison of a Gerber extracted netlist and an IPC-D-356 netlist can be performed. Automatic fixing of certain errors can occur with built-in verification to ensure new errors are not created. Parameters can be saved for repeat use thus cutting down setup times. More powerful than simple pass/fail results, many checks distinguish between critical and potential errors. With over 60 DFM checks, finding issues with signal layers, soldermasks, silkscreen, and plane layers is thorough and accurate.
Robust editing allows quick panelization including venting, thieving and coupons Programs plotters, drill machines, testers
